IBC SL Boiler
The IBC wall-mounted SL G3 residential condensing boilers convert natural gas or propane into heat with unprecedented efficiency, helping to stretch our precious supply of fossil fuels well into the future. IBC are dedicated to finding new and better ways to utilize the world’s dwindling energy resources while providing superior comfort, reliability and fuel savings.
-
Specifications
- Built-in 4 zone pump or valve control in addition to the primary control. 5 pumps total. Replacing the need for external pump controls
- PVC/CPVC/PPs approved – venting up to 240ft (each side) on the VX 110
- Built-in CSA/UL approved LWCO and manual reset high limit.
- Turndown ratio of up to 8:1 means you have the power to heat your home in the coldest weather, yet reduce short cycling when the weather is mild.
- Reverse flow detection.
- 5 Year Parts Warranty & Limited Lifetime residential heat exchanger warranty.
- Up to 96% AFUE with full ASME-rated heat exchanger
- Express setup with easy remote diagnostics and troubleshooting
-
Where to buy
Units are stocked locally. Complete in house design and technical support is available 8:00am to 5:00pm with on call tech support after hours. If you are looking for design help or an installer in your area contact us at 800-665-3336 x 206 or email us at info@edenenergy.com
-
Technical Specs
Specifications SL10-85 SL14-1115 Sl20-160 Sl30-199G3 CSA Input (Natural Gas or Propane) – MBH 10.6 - 85 14 - 115 20 - 160 32 - 199 CSA Output – MBH 10.1 - 79 13.3 - 109 19.0 - 147 30 - 181.3 A.F.U.E 96% 95% 95% 95% Min gas pressure (Nat. Gas or Propane) – inch w.c. 4 4 4 4 Max Gas Pressure (Nat. Gas or Propane) – inch w.c. 14 14 14 14 Power (120Vac/60Hz) – Watts @ full fire with internal pump 54 54 73 82 Pressure vessel water content – USG 2.47 2.47 1.72 5.09 Max boiler flow rate – USgpm 14 14 19 22 Min boiler flow rate – USgpm 2 2 4 6 Max operating pressure psig 30 30 30 30 Min water pressure – psig 8 8 8 8 Min water temperature – Space Heating (°F/°C) 34 / 1 34 / 1 34 / 1 Max water temperature – Space Heating (°F/°C) 190 / 88 190 / 88 190 / 88 Max equivalent vent length 2″ (each side) 100′ 100′ 35′ N/A Max equivalent vent length 3″ (each side) 240′ 240′ 170′ 150′ Boiler Head Loss - SL10-85G3 Flow Rate - GPM 2 4 6 8 10 12 14 Head Loss- Ft. 0.5 1.5 2.5 3.0 4.0 4.5 6.0 Boiler Head Loss - SL14-115G3 Flow Rate - GPM 2 4 6 8 10 12 14 Head Loss- Ft. 0.5 1.5 2.5 3.0 4.0 4.5 6.0
